M4000

SMARTIA M4000 Polycarbonate Sheets

Descriptions

The SMARTIA M4000 Polycarbonate system has various polycarbonate sheets, hollow and solid, together with the aluminum profiles needed. Atriums, skylights, car shades, interior partitions, windows, greenhouses, sliding roof systems and sound barriers etc. It is the best choice for

Advantages

Two different types (hollow and solid) and various thickness, color and partition options
More practical construction compared to other traditional materials such as glass
Lightness, flexibility, unbreakability, heat insulation, transparency, sound insulation and UV protection
Easy cleaning thanks to its dust-proof feature
Different standard and custom sizes

Generic

TYPES
empty and full
MATERIAL
Sabic PC Resin
FEATURES
Sound insulation, waterproof, hard to break, easy to clean, fireproof, UV protected

Technicial Specifications

THICKNESS
4-40mm hollow plate, 2-10mm solid plate
LAYERS
2-7 layers
STANDARD SIZE
2100 x 6000mm (with void4-20mm thickness), 1250 x 6000mm (with void 20-40mm thickness), 2050 x 6100mm (solid)
WEIGHT
0.8 – 3.2 Kg/m2
HEAT CONDUCTION
2.2 W/m2K for 20mm, 3.9 W/m2K for 4.0mm
UV HEATING
UV protection on material surface
LINEAR DISORDER
0.065mm/m°C
FIRE RESISTANT
Class 1
COLOR VARIETY
transparent, bronze, green, blue, white

TYPOLOGIES

All typologies

Sections

SMARTIA aluminium systems
